Redarc 24V 20A DC/DC Charger (Under Bonnet) Low Voltage

The BCDC2420-LV is a 24 Volt 20 Amp low voltage In-vehicle DC Charger featuring technology designed to charge all major lead acid batteries to a proven 100%.* It’s suitable for vehicles fitted with an ECU-controlled variable voltage alternator and is fully potted making it ideal for high heat, dust and vibration commonly experienced in under bonnet installations.

*large capacity battery banks may require a few cycles to fully charge.



Three stage charging profile
The REDARC BCDC2420-LV Low Voltage battery charger is a three stage DC DC charger that operates from a vehicle input between 9 and 32 Volts DC. It is designed to charge AGM, gel, VRLA and standard lead acid automotive 24V battery systems to an optimal level with chemistry specific battery charging algorithms.



Perfect for trucking and heavy vehicle applications
The BCDC2420-LV features a multi-stage charging algorithm, with a 24V charging output the DC to DC charger is perfectly suited to trucking applications such as charging battery banks for tailgate lifters and side curtains.



DC to DC battery with in-built MPPT solar regulator
The BCDC2420-LV features a MPPT Solar Regulator, which means 12V solar panels can be used to charge your 24V auxiliary batteries. The MPPT Solar charging algorithm extracts the maximum available power from your solar panels at any given time.



Features
Multi Stage DC to DC Battery Charger
MPPT Solar Regulator
Start Battery Isolator
Fully sealed
No fan for super quiet operation
Charges AGM, Gel, Calcium content, VRLA and Standard Lead Acid batteries

Input (Operating) Voltage 9 - 32VDC
Input Charge Vehicle or solar
Installation Type In-cabin or under bonnet
Output Current Rating (Cont.) 20A, 20A
Maximum Charging Voltage 30.6V
Input Fuse Rating 50A
Output Fuse Rating 30A
Warranty 2 Years
Standby Current Draw <50mA
Output System Voltage 24VDC
Output Power 600W
Length (mm) 150
Width (mm) 120
Height (mm) 37
Weight (kg) 0.68
Type Approval E and CE
